CHAPTER 3 | PMI OPERATION MANUAL
MAINTENANCE MODE 3-11
10:53
Category text information
Menu:Maint:Control:ChangeASD
PHY:FireFinder@1, DLC@1, HFP11@2
Cancel
CHANGE ASD
AT: FireFinder@1, DLC@1, HFP11@2
# ASD Devices: 1
SETTINGS:
FROM: Disable
TO: Office
Execute
Figure 3-18
Change ASD Setting Status Screen
At this point, the ASD setting has not been changed.
Press the Execute soft key to change the ASD setting.
Control - Change Sens Use the Change Sensitivity feature to change the sensitivity (percent/ft. obscuration)
settings at the PMI for any chosen device.
While in Maintenance mode, navigate to the desired module/loop or device by
pressing the More Info+/- buttons.
Change Sensitivity operations can only be performed at the device level. These
operations will appear grayed out on the PMI when the system is set at any other
level. They will also appear grayed out when an ASD setting is enabled for the
device.
Press the Control soft key. (If the appropriate level password has not been previously
entered or if it has timed out, the Enter Password screen displays. See page 3-1.) The
Control menu displays. Touch the box labeled Change Sensitivity and a screen
displays showing the current sensitivity setting. See Figure 3-19.
Menu:Maint:Control:Change Sensitivity
PHY:FireFinder@1, DLC@1, HFP11@2
CHANGE SENSITIVITY
AT: FireFinder@1, DLC@1, HFP11@2
# Sensitivity Devices: 1
Cancel Settings Execute
SETTINGS:
FROM: 3.00% / Foot
TO : Not Set
Figure 3-19
Change Sensitivity Screen
