5. Technical description
Observe the instructions in section 3, "Safety instructions"!
5.1 General description
The gear unit described is a planetary gear unit developed for use in bucketwheel excavators.
The bucketwheel drive is delivered as a complete drive unit assembled from various components.
2
7
34
65
1
8
Fig. 4: Gear unit components
1 Bevelhelical planetary gear unit 5 Protective cover
2 Torque arm 6 Coupling
3 Ball and socket joint (optional) 7 Brake
4 Setting screws for electrical motor 8 Shrink disk
A detailed view of the gear unit can be obtained from the drawings in the gearunit documentation.
