1.1.1 Measuringsurface soundpressure level
The gear unit has a measuringsurface soundpressure level at a distance of 1 m, which can be found in
table 1.
The measurement is carried out to DIN EN ISO 9614 Part 2, using the soundintensity method.
The workplace of the operating personnel is defined as the area on the measuringsurface at a distance
of 1 metre in the vicinity of which persons may be present.
The soundpressure level applies to the warmedup gear unit at input speed n
1
and output power P
2
stated
on the rating plate, as measurement obtained on the Siemens test bench. If several figures are given, the
highest speed and power values apply.
The measuringsurface soundpressure level includes addon lubrication units, if applicable. With
outgoing and incoming pipes, the interfaces are the flanges.
The soundpressure levels stated in the table were obtained by statistical calculation by our Quality Control
Dept. The gear unit can be statistically expected to comply with these soundpressure levels.
Table 1: Measuringsurface soundpressure level
Type
i
N
Gearunit size
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 38 40 42
PBUC
112 ... 160
97 97 98 98 99 99 100 100 101 101 102 102 103 103 104 104 105 106 106
180 ... 250
95 95 96 96 97 97 98 98 99 99 100 100 101 101 102 102 103 103 103
280 ... 450
93 93 94 94 95 95 96 96 97 97 98 98 99 99 100 100 102 102 102
The measuringsurface soundpressure levels shown apply with a tolerance of + 3 dB(A) for
n
1
= 1500 1/min.
At n
1
= 750 1/min, the values will be appr. 2 to 3 dB(A) lower.
