Intended use of Siemens products
Observe also the following:
Siemens products must be used only for the applications provided for in the catalogue and the relevant
technical documentation. If products and components of other makes are used, they must be
recommended or approved by Siemens. The faultfree, safe operation of the products calls for proper
transport, proper storage, erection, assembly, installation, startup, operation and maintenance. The
permissible ambient conditions must be adhered to. Notes in the relevant documentations must be
observed.
Trademarks
All designations indicated with the registered industrial property mark ® are registered trademarks of Siemens AG.
Other designations used in these instructions may be trademarks the use of which by third parties for their own
purposes may infringe holders’ rights.
Exclusion of liability
We have checked the content of the instructions for compliance with the hard and software described.
Nevertheless, variances may occur, and so we can offer no warranty for complete agreement. The information
given in these instructions is regularly checked, and any necessary corrections are included in subsequent editions.
Symbols
Earth connection point Air relief point yellow
Oilfilling point
yellow Oildraining point white
Oil level
red Oil level red
Oil overflow
Connection for
vibrationmonitoring device
Lubrication point red Apply grease
Lifting eye Eye bolt
Do not unscrew
Alignment surface, horizontal Alignment surface, vertical
These symbols indicate the oillevel checking procedure using the oil dipstick.
These symbols indicate that the oil dipstick must always be firmly screwed in.
