Mounting and connecting the device
4.1 Mounting the device
4.1.1 Mounting position
The installation should provide a dry environment for the LOGO! CIM. SELV/PELV circuits are
considered to provide protection against electric shock in dry locations.
The CIM installation dimensions are compliant with DIN 43880.
CIM can be snap-mounted to 35 mm DIN rails according to EN 60715 or mounted on the wall
with two M4 screws.
LOGO! CIM has a width of 71.5 mm.
isk to life when you touch live parts
Death or serious injury can result when you touch live parts.
Always switch off power before you remove or insert an expansion module.
The device is approved for indoor operation only.
Installation location - Dependency of the temperature range
The upper and lower ventilation slits of CIM cannot be covered, allowing adequate
ventilation. Above and below the module, there must be a clearance of 25 mm to allow air
to circulate and prevent overheating.
