Web-based configuration
5.4 Web pages
LOGO! CIM
54 Operating Manual, 10/2021, A5E51250518-AA
4. Set the action type.
Action Action
source
Target restriction Remark
1
Set new value
variable
Permitted data type: all
UDM permitted data type.
2
Copy value from
event
The variable type of the
action must be the same as
the variable type of the
source event it copied from.
If the event is "receive mes-
sage" and the event source is a
message without variable,
then this action cannot be
configured.
3
Increase by value
Permitted data type: all
UDM permitted data type
except bool.
• The increase or decrease
value can only be positive.
• If the variable reaches the
maximum or minimum
value of its range, the vari-
able will not increase or
decrease any more.
4
Decrease by value
5
Send message
Message
• If the event is "receive
message", this action type
cannot be configured.
• If the message contains a
parameter, the parameter
is the event parameter.
6
Send variable
Variable
• The format of the message
is:
variable name = value
(short type)
If the variable is in hexa-
decimal, 0x is added before
the value, for example,
v0.0 = 0x10(b)
• If the event is "receive
message" and the event
source is a message with-
out variable, then this ac-
tion cannot be triggered.
5. Configure the action.
– If the action is a variable change, you need to select a variable from the variable list
and fill the new value in the input box below To.
– If the action is sending a message, you need to select a message from the message list.
6. Enable the bind.
