Siemens LOGO! CIM - Page 61

Web-based configuration
5.4 Web pages
LOGO! CIM
Operating Manual, 10/2021, A5E51250518-AA
61
7. Input the length of the data need to be transferred ⑦.
8. Input the Unit ID ⑧.
9. To set the time interval that CIM synchronizes the data with the server, enable the
customized interval and input the specified time interval ⑨.
The default minimum transmit interval is 80 milli-second.
10.Save your changes and close the data transfer table.
Data transfer restrictions
The table below describes the range and local address restrictions for client connections.
Local address (LOGO! CIM) Remote address (Modbus TCP com-
patible device)
Address Type
Range
Address Type
IB
0.0 to 511.7
Coil
Discrete Input (DI)
QB
0.0 to 511.7
MB
0.0 to 511.7
VB
0.0 to 1023.7
IW
0 to 510
Holding Register (HR)
Input Register (IR)
QW
0 to 510
MW
0 to 510
VW
0 to 1022
Note
The address type is the combination of the process image name in
UDM (Page 9) and data
type. For example, IB means bit in memory I.
The values should follow the rule: Local address + Data length
≤ Max value of Local address
type.
