Siemens AG SPR8-220.031.04 Page 1 of 4 MOBILETT Plus/ -E/ -HP
Medical Solutions Rev. 04 09.03 CS PS 24
Prerequisites 1
Purpose 1
This document describes how to install a DAP measuring system (Dose Area Product
measuring system) on a MOBILETT Plus/ Plus E/ Plus HP.
General 1
The DAP equipment is designed for the measurement of the area kerma product
(kerma = kinetic energy released in matter) during an X-ray examination. It is especially
used to record the radiation dose to which the patient is exposed.
Systems / products 1
This installation instruction is only valid for:
MOBILETT Plus with Serial No. higher than 2350
MOBILETT Plus E with Serial No. higher than 10200
MOBILETT Plus HP with Serial No. higher than 30001
Important note 1
Store the document "Supplement to the Instructions for Use" together with the MOBILETT
Instructions for Use as a reference on how to use the DAP meter after installation.
Components included 1
The kit (Part No. 66 13 082) contains the following parts:
To facilitate possible troubleshooting, store this document along
with the Technical Manual
.
Pos No. Quantity Part No. Name
1 2 65 57 156 Belt
2 1 65 84 960 DAP ionization chamber
3 1 65 61 992 Cable K9a, K9b, K21, K22, K23
4 1 65 61 927 Cable K52a, K52b, K23, K24, K25
5 1 65 78 772 Board D70
6 1 65 84 937 Lower arm cover with mounted display
7 1 65 84 697 Upper arm cover
8 1 65 84 655 Collimator cover incl. handle
9 20 64 57 840 Cable ties, 2.5x100mm
10 10 60 89 577 Cable ties, 4.7x195mm
11 1 65 08 985 Clamp for cable to Ionization chamber
12 1 60 94 023 Spiral cable tie, length 260 mm at rest
13 8 69 99 361 Soldering coil
