Prerequisites 1 - 3
Siemens AG SPR8-220.031.04 Page 3 of 4 MOBILETT Plus/ -E/ -HP
Medical Solutions Rev. 04 09.03 CS PS 24
Tools / documents required 1
• Standard installation tools
• Soldering iron
• The document Service Instructions for the relevant MOBILETT
• Set of ring spanners / open end keys, including a key for 5.5 mm diameter
• Drill and drill bit for 5 mm diameter
Time required 1
• Approximately 8 hours for one customer support engineer.
Safety information 1
Dangerous x-ray radiation and/or dangerous electrical voltage
during checks and adjustment work steps!
If not observed, death or serious physical injury can occur.
The following items must be complied with when performing ser-
vice work and tests:
- The product-specific safety information in the documents,
- The general safety information contained in ARTD Part 2.
• Connect the MOBILETT only to a mains power supply outlet
(receptacle) that corresponds to the installation requirements of
VDE 0107 or to country-specific regulations.
• Remove or install boards only when the generator is switched
OFF. Adhere to the ESD guidelines .
• Checks and adjustments performed with radiation ON are
identified by the radiation warning symbol . Radiation
protective clothing must be worn for this type of adjustment (see
ARTD, Part 2).
WARNING
