Siemens POLYMOBIL Plus Maintenance Instruction

32 Inspection and Maintenance
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 32 of 40
Medical Solutions
Fig. 10: kV and tube current
• If no oscillogram is produced, adjust as described in the Service Instructions.
• Switch the Polymobil Plus OFF and disconnect the line voltage plug.
• Close the control console.
QSQ Coincidence of light field and radiation field
NOTE
If the POLYMOBIL is equipped with a DAP measuring system, re-
move the DAP ionization chamber first.
Fig. 11: Preparation: light field and radiation field
Pos. 1 Length
Pos. 2 Marker
Pos. 3 Side marker
