Siemens RUGGEDCOM RSG2488 - Inserting;Removing the Microsd Card

Device Management
3.3Inserting/Removing the MicroSD Card
3.3 Inserting/Removing the MicroSD Card
The RUGGEDCOM RSG2488 accepts a microSD card for storing configuration files
and/or software updates.
NOTICE
Configuration hazard – risk of data loss
The microSD card must not be removed or replaced during normal operation of the
device. Make sure the device is powered down before removing or inserting the
card.
NOTICE
Mechanical/electrical hazard – risk of damage to the microSD card
• Do not expose the microSD card to extreme temperatures or humidity
• Do not expose the microSD card to large magnetic or static electric fields
• Do not bend or drop the microSD card
NOTICE
Security hazard – risk of unauthorized access and/or exploitation
Make sure to remove the microSD card before decommissioning the device or
sending the device to a third-party.
To insert or remove a microSD card, do the following:
1. Power down the device.
2. Unscrew the retention screws and remove the access plate.
2
1
1
Access Plate
2
MicroSD Card
Figure3.3 Inserting/Removing a MicroSD Card
3. Without touching the contacts on the card, insert or remove the microSD card.
4. Install the access plate and finger-tighten the retention screws.
5. Power up the device.
RUGGEDCOM RSG2488
Installation Manual, 07/2021, C79000-G8976-1048-11
23
