Siemens RUGGEDCOM RSG2488 Installation Manual

Modules
4.3Installing/Removing Power Modules
4. Insert the new module into the slot.
3
1
2
1
Module
2
Chassis
3
Screw
Figure4.3 Installing a Module
5. Tighten the screws to secure the module.
6. [Optional] If necessary, install the device in the rack.
7. Connect power to the device.
4.3 Installing/Removing Power Modules
The RUGGEDCOM RSG2488 supports dual redundant power supply modules.
1 2
1
Power Supply Module (PS1)
2
Power Supply Module (PS2)
Figure4.4 Power Supply Modules
NOTICE
Contamination hazard – risk of equipment damage
28
RUGGEDCOM RSG2488
Installation Manual, 07/2021, C79000-G8976-1048-11
