Modules
4.2Installing/Removing Line Modules
4. Pull the module from the chassis to disconnect it.
3
1
2
1
Module
2
Chassis
3
Screw
Figure4.2 Removing a Module
5. Install a new module or a blank module (to prevent the ingress of dust and dirt).
6. [Optional] If necessary, install the device in the rack.
7. Connect power to the device.
Installing a Module
To install a line module, do the following:
1. Make sure power to the device has been disconnected and wait approximately
two minutes for any remaining energy to dissipate.
2. [Optional] If the device is installed in a rack, remove it from the rack.
3. Remove the current module from the slot.
RUGGEDCOM RSG2488
Installation Manual, 07/2021, C79000-G8976-1048-11
27
