Siemens RUGGEDCOM RSG2488 Installation Manual

Certification
6.2EMC and Environmental Type Tests
• IEC 61000-6-2
Electromagnetic Compatibility (EMC) – Part 6-2: Generic Standards – Immunity
for Industrial Environments
6.2 EMC and Environmental Type Tests
The RUGGEDCOM RSG2488 has passed the following EMC and environmental tests.
EMC Type Test for IEC 61850-3
Note
• In the case of an all fiber port configuration, this product meets all Class 2
requirements. Otherwise, all Class 1 requirements are met for copper ports.
• If the unit contains copper ports, the IEC 1613 conformance is Class 1, during
which disturbance errors may occur but recovery is automatic.
• If the unit contains all fiber ports, the IEC1613 conformance is Class 2, during
which no disturbance errors will occur.
Test Description Test Levels Severity Levels
Enclosure Contact ± 8 kVIEC 61000-4-2 ESD
Enclosure Air ± 15 kV
4
IEC 61000-4-3 Radiated RFI Enclosure Ports 20 V/m
Signal Ports ± 4 kV @ 2.5
and 5 kHz
Note
a
DC Power Ports
AC Power Ports
± 4 kV @ 2.5
and 5 kHz
IEC 61000-4-4 Burst (Fast
Transient)
Earth Ground Ports ± 4 kV @ 5 kHz
Signal Ports ± 4 kV Line-
to-Earth
± 2 kV Line-to-Line
4
DC Power Ports ± 2 kV Line-
to-Earth, ± 1
kV Line-to-Line
3
IEC 61000-4-5 Surge
AC Power Ports ± 4 kV Line-
to-Earth
± 2 kV Line-to-Line
4
Signal Ports
DC Power Ports
AC Power Ports
IEC 61000-4-6 Induced
(Conducted) RFI
Earth Ground Ports
10 V 3
100 A/m for 3 minIEC 61000-4-8 Magnetic Field Enclosure Ports
1000 A/m for 3 s
5
40
RUGGEDCOM RSG2488
Installation Manual, 07/2021, C79000-G8976-1048-11
