Modules
4.1Available Modules
Slot Module Type
PS1 and PS2 Power Supply Module
1 4-Port Copper Ethernet, Fiber Optic Ethernet, SFP Transceiver or PTP Module
2 to 6 4-Port Copper Ethernet, Fiber Optic Ethernet or SFP Transceiver
7 to 8 2-Port Copper Ethernet, Fiber Optic Ethernet or SFP Transceiver
4.1 Available Modules
A variety of modules are available for use with the RUGGEDCOM RSG2488.
For more information, refer to the RUGGEDCOM Modules Catalog [https://
support.industry.siemens.com/cs/us/en/view/109757282] for the RUGGEDCOM
RSG2488.
4.2 Installing/Removing Line Modules
Upon installing a new line module in the device, all features associated with the
module are available in RUGGEDCOM RSG2488. For more information, refer to the
RUGGEDCOM ROS Configuration Manual for the RUGGEDCOM RSG2488.
Once a line module is removed, all the features associated with the module are
hidden or disabled in RUGGEDCOM RSG2488.
NOTICE
Only one Precision Time Protocol (PTP) line module is supported per chassis.
NOTICE
Contamination hazard – risk of equipment damage
Prevent the ingress of water, dirts and other debris that may lead to premature
equipment failure. Always make sure slots are not left empty and open ports are
protected with plugs or covers.
Removing a Module
To remove a line module, do the following:
1. Make sure power to the device has been disconnected and wait approximately
two minutes for any remaining energy to dissipate.
2. [Optional] If the device is installed in a rack, remove it from the rack.
3. Loosen the screws that secure the module.
26
RUGGEDCOM RSG2488
Installation Manual, 07/2021, C79000-G8976-1048-11
