Siemens RUGGEDCOM RSG2488 Installation Manual

Technical Specifications
5.3Supported Networking Standards
5.3 Supported Networking Standards
Standard 10 Mbps 100 Mbps
1000
Mbps
Notes
IEEE 802.1AB Yes Yes Yes Link Layer Discovery Protocol (LLDP)
IEEE 802.1D Yes Yes Yes MAC bridges
IEEE 802.1Q Yes Yes Yes VLAN (Virtual LAN)
IEEE 802.1p Yes Yes Yes Priority levels
IEEE 802.1x Yes Yes Yes Port-based network access control
IEEE 802.3 Yes No No 10Base-T
IEEE 802.3u No Yes No 100Base-TX/100Base-FX
IEEE 802.3z No No Yes 1000Base-SX/LX
IEEE 802.3ab No No Yes 1000Base-TX
IEEE 802.3x Yes Yes Yes Full duplex operation
5.4 Operating Environment
Ambient Operating
Temperature
ab
-40 to 85 °C (-40 to 185 °F)
Ambient Storage
Temperature
-40 to 85 °C (-40 to 185 °F)
Ambient Relative
Humidity
c
5% to 95%
Maximum Altitude 2000 m (6562 ft)
a
Measured from a 30 cm (11.8 in) radius surrounding the center of the enclosure.
b
Operating temperature may vary based on the limitations of installed SFPs. Refer to the RUGGEDCOM
SFP Transceivers Catalog for SFP temperature ratings.
c
Non-condensing.
5.5 Mechanical Specifications
Weight 8.6 kg (19 lbs)
Ingress Protection IP30
Enclosure Aluminum
5.6 Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
32
RUGGEDCOM RSG2488
Installation Manual, 07/2021, C79000-G8976-1048-11
