Mounting
4.2 Mounting with adapter plate
SCALANCE W-784-1xx / SCALANCE W-74x-1
68 Operating Instructions (Compact), Release 08/2007, A5E01174713-02
Secure the SCALANCE W784-1xx / W74x-1 to the wall using four screws. The screws are
not supplied with the device. The type and length of the screws depend on the type of wall.
Note
The minimum clearance between the SCALANCE W784-1xx / W74x-1 and fluorescent
lamps should be 0.5 m.
4.2 Mounting with adapter plate
4.2.1 Fitting the adapter plate to an S7-300 standard rail
Procedure
B
A
Figure 4-2 Side view of an S7-300 standard rail (shown in gray) with an adapter plate fitted
