3.3 LED display
SCALANCE W-784-1xx / SCALANCE W-74x-1
Operating Instructions (Compact), Release 08/2007, A5E01174713-02
61
3.3 LED display
Information on operating status and data transfer
On the front of the housing, several LEDs provide information on the operating status of the
SCALANCE W784-1xx / W74x-1:
SCA
LANCE
L1
PoE
P1
R1
F
s
L1
PoE
P1
R1
F
Figure 3-1 LEDs of the SCALANCE W784-1xx / W74x-1
