Connecting up
5.2 Suitable antenna cables and antennas for SCALANCE W-700
SCALANCE W-784-1xx / SCALANCE W-74x-1
Operating Instructions (Compact), Release 08/2007, A5E01174713-02
77
Antennas
The following antennas have been approved for use with a SCALANCE W-700:
Type Properties Order No.
ANT795-6MN Omni antenna 2.4 / 5 GHz,
ceiling mounted
6GK5795-6MN00-0AA6
ANT792-6MN Omni antenna 2.4 GHz,
wall mounted
6GK5792-6MN00-0AA6
ANT793-6MN Omni antenna 5 GHz,
wall mounted
6GK5793-6MN00-0AA6
ANT792-8DN Directional antenna 2.4 GHz,
wall mounted
6GK5792-8DN00-0AA6
ANT793-8DN Directional antenna 5 GHz,
wall mounted
6GK5793-8DN00-0AA6
ANT795-6DN Directional antenna 2.4 / 5 GHz,
wall mounted
6GK5795-6DN00-0AA6
ANT795-4MR Omni antenna 2.4 / 5 GHz,
mounted directly on a
SCALANCE W788-xPRO/RR or
W74x-1PRO/RR
6GK5795-4MR00-0AA6
ANT795-4MS Omni antenna 2.4 / 5 GHz,
mounted directly on a
SCALANCE W788-xPRO/RR or
W784-1xx or W74x-1PRO/RR
or W74x-1
6GK5795-4MS00-0AA6
ANT792-4DN RCoax antenna 2.4 GHz 6GK5792-4DN00-0AA6
ANT793-4MN RCoax antenna 5 GHz 6GK5793-4MN00-0AA6
