Siemens SCALANCE X-400 User Manual

Technical specifications
8.1 SCALANCE X414-3E and X408-2 - technical specifications
SCALANCE X-400
140 Operating Instructions, 06/2015, C79000-G8976-C186-12
SCALANCE X414-3E
SCALANCE X408-2
Current consumption at 24 V DC
< 2000 mA
< 700 mA
Load on the signaling contact 24 V DC / max. 100 mA safety
extra-low voltage (SELV)
24 V DC / max. 100 mA safety
extra-low voltage (SELV)
Overvoltage protection at input Non-replaceable fuse (F 3.15 A /
250 V)
Non-replaceable fuse (F 3 A /
32 V)
Digital Inputs Input voltage:
• Rated value 24 V DC safety
extra-low voltage (SELV)
• For state "1": + 13 V ...+ 30 V
• For state "0": – 30 V to + 3 V
Max. input current: 8 mA
Max. cable length: 30 m
Inputs isolated from electronics.
Inputs not present.
C-PLUG
SCALANCE X414-3E
SCALANCE X408-2
Dimensions (width x height x
depth)
24.3 x 17.0 x 8.1 mm 24.3 x 17.0 x 8.1 mm
Weight
approx. 5 g
approx. 5 g
Power consumption
0.015 W
0.015 W
Memory capacity
32 Mbytes
32 Mbytes
Permitted cable lengths
SCALANCE X414-3E
SCALANCE X408-2
TP cable length With TP cord up to 10 m, with
FastConnect cabling system up
to 100 m.
With TP cord up to 10 m, with
FastConnect cabling system up
to 100 m.
Redundancy reconfiguration times
Redundancy
Reconfiguration times
HRP
300 ms
Standby link
300 ms
MRP
200 ms
