Parameter Setting Preparation
104 SICAM TM, Installation
Ausgabedatum 10.2014, DC6-015-2.04
12.1. Introduction
The SICAM TM system is parameterized with a PC on which the SICAM TOOLBOX II
software is installed. For this, the SICAM TOOLBOX II and automation unit must be
connected with each other and a Flash Card configured in the master control element:
12.2. Physical connection between SICAM TOOLBOX II and
SICAM TM
Following connections are differentiated:
· direct local via toolbox cable
· serial via modems
· Ethernet (TCP/IP)
· Ethernet (TCP/IP) and Terminal Server (serial)
