Siemens simatic c7-621 Hardware Installation Guide

2-9
C7-621 / C7-621 AS-i Control Systems
C79000-G7076-C621-01
Table 2-2 Pinout of the Digital Inputs, continued
Pin FunctionSignal
1.6 I125.6 Digital input 14
1.7 I125.7 Digital input 15
Table 2-3 Pinout of the Digital Outputs
Pin Signal Function
0.0 Q124.0 Digital output 0
0.1 Q124.1 Digital output 1
0.2 Q124.2 Digital output 2
0.3 Q124.3 Digital output 3
0.4 Q124.4 Digital output 4
0.5 Q124.5 Digital output 5
0.6 Q124.6 Digital output 6
0.7 Q124.7 Digital output 7
1.0 Q125.0 Digital output 8
1.1 Q125.1 Digital output 9
1.2 Q125.2 Digital output 10
1.3 Q125.3 Digital output 11
1.4 Q125.4 Digital output 12
1.5 Q125.5 Digital output 13
1.6 Q125.6 Digital output 14
1.7 Q125.7 Digital output 15
Digital Ouput
Installing and Preparing the C7
