Siemens SIMATIC ET 200PA SMART+ Equipment Manual

Article number 6DL1161-6BH00-0PH1
Short-circuit protection Yes; electronic (response threshold 0.7 A to 1.3 A;
for IO redundancy up to 2.6 A) Ensure su󹪟cient
low-resistance cable routing to the sensor/actuator
in order to attain the response threshold. Depend‐
ing on the cable cross-section used, there may be
constraints regarding the usable length of cable
Output current 
• up to 60 °C, max.
2A; 1 A when mounted vertically; see derating in‐
formation in Equipment Manual
• up to 70 °C, max.
1 A; See derating information in Equipment Manual
24 V encoder supply 
• 24 V
Yes
• Short-circuit protection
Yes; electronic (response threshold 0.7 A to 1.3 A;
for IO redundancy up to 2.6 A) Ensure su󹪟cient
low-resistance cable routing to the sensor/actuator
in order to attain the response threshold. Depend‐
ing on the cable cross-section used, there may be
constraints regarding the usable length of cable
• Output current per channel, max.
0.5A
• Output current per module, max.
2A
Power 
Power available from the backplane bus 80mW
Power loss 
Power loss, typ. 3.6W; Maximum value (taking the max. encoder
current and the max. operating voltage into ac‐
count)
Address area 
Address space per module 
• Address space per module, max.
2byte; + 2 bytes for QI information
Hardware con󹪝guration 
Automatic encoding 
• Mechanical coding element
Yes
Digital inputs 
Number of digital inputs 16
Digital inputs, parameterizable Yes
Source/sink input Yes; P-reading
Input characteristic curve in accordance with IEC
61131, type 1
Yes
Input characteristic curve in accordance with IEC
61131, type 2
No
Input characteristic curve in accordance with IEC
61131, type 3
Yes
Pulse extension Yes
• Length
o󹪜, 50 ms, 100 ms, 200 ms, 500 ms, 1 s, 2 s
Time stamping Yes; Resolution 10 ms
Time stamp (with precision of 1 ms) No
Edge evaluation Yes; rising edge, falling edge, edge change
Technical speci󹪝cations
DI 16x24VDC PA
32 Equipment Manual, 06/2023, A5E51654101-AA
