Siemens SIMATIC ET 200PA SMART+ Equipment Manual

Article number 6DL1161-6BH00-0PH1
Input voltage 
• Rated value (DC)
24V
• for signal "0"
-30 to +5 V
• for signal "1"
+11 to +30V
Input current 
• for signal "1", typ.
2.5mA
Input delay (for rated value of input voltage) 
for standard inputs 
– parameterizable
Yes; none / 0.05 / 0.1 / 0.4 / 0.8 / 1.6 / 3.2 / 12.8 / 20
ms
Cable length 
• shielded, max.
1000m
• unshielded, max.
600m
Encoder 
Connectable encoders 
• 2-wire sensor
Yes
– permissible quiescent current (2-wire
sensor), max.
1.5mA
Interrupts/diagnostics/status information 
Diagnostics function Yes
Alarms 
• Diagnostic alarm
Yes; channel by channel
• Hardware interrupt
Yes; channel by channel
Diagnoses 
• Diagnostic information readable
Yes
• Monitoring the supply voltage
Yes; Module-wise
– parameterizable
Yes
• Monitoring of encoder power supply
Yes
• Wire-break
Yes; Channel-by-channel, optional protective cir‐
cuit for preventing wire-break diagnostics in the
case of simple encoder contacts: 15 kOhm to 18
kOhm
• Short-circuit to M
Yes; Encoder supply to M, channel by channel
Diagnostics indication LED 
• MAINT LED
Yes; Yellow LED
• Monitoring of the supply voltage (PWR-LED)
Yes; green PWR LED
• Channel status display
Yes; green LED
• for channel diagnostics
No
• for module diagnostics
Yes; green/red LED
Potential separation 
Potential separation channels 
• between the channels
No
• between the channels and backplane bus
Yes
Technical speci󹪝cations
DI 16x24VDC PA
Equipment Manual, 06/2023, A5E51654101-AA 33
