Properties
IM151-1 FO STANDARD interface module (6ES7151-1AB05-0AB0)
Manual, 02/2010, A5E01075965-03
9
Technical data for IM151-1 FO STANDARD (6ES7151-1AB05-0AB0)
Dimensions and weight
Dimension B (mm) 45
Weight Approx. 150 g
Module-specific data
Data transmission rate 9.6; 19.2; 45.45; 93.75; 187.5; 500 kBaud,
1.5;12 Mbit/s
Bus protocol PROFIBUS DP
Interface Fiber-optic cable
SYNC capability yes
FREEZE capability yes
Manufacturer ID 806B
H
Direct data exchange yes
Cycle synchronization No
Parameter length 27 bytes
Address space 244 bytes I/O
Option handling
With reserve module
Yes
Without reserve module
yes
I&M data yes
Firmware update via PROFIBUS DP with STEP7
Voltages, currents, potentials
Rated supply voltage of the electronic
components (1L+)
24 VDC
Incorrect polarity protection
yes
Power failure bypass
Min. 20 ms
Galvanic isolation
Between the backplane bus and electronic
components
No
Between the supply voltage and electronic
components
No
Permitted potential difference (to the rail) 75 V DC, 60 V AC
Insulation tested with 500 VDC
Current consumption from rated supply voltage
(1L+)
Approx. 200 mA
Power dissipation of the module Typically 3.3 W
Status, interrupts, diagnostics
Interrupts yes
Diagnostic function yes
Group error
Red "SF" LED
PROFIBUS DP bus monitoring
Red "BF" LED
Monitoring of the power supply voltage of the
electronics
Green "ON" LED
