Product Overview
1.3 Using ET 200S Fail-Safe Modules
ET 200S Distributed I/O System - Fail-Safe Modules
14 Installation and Operating Manual, 08/2008, A5E00103686-07
1.3 Using ET 200S Fail-Safe Modules
Possible Uses of ET 200S with Fail-Safe Modules
The use of ET 200S with fail-safe modules enables conventional safety engineering designs
to be replaced with PROFIBUS DP/PROFINET IO components. This includes the
replacement of switching devices for emergency STOP, protective door monitors, two-hand
operation, etc.
Use in F-Systems
Fail-safe ET 200S modules can be used:
● In the S7 Distributed Safety F-system with the
S7 Distributed Safety
optional package
V5.2 or higher
● In the S7 F/FH Systems with the
S7 F Systems
optional package version V5.2 SP 3 or
higher
● To interface ET 200S fail-safe modules to PROFIBUS DP with Distributed Safety or S7
F/FH systems, you need:
– ET 200S fail-safe modules
– F-CPU
–
STEP 7
V5.3 SP3 or higher
– IM151-1 DP HIGH FEATURE interface module
–
S7 Distributed Safety
V5.2 or higher (for the order numbers specified in the "Preface":
F Configuration Pack
Version V5.5 SP5 or higher)
The
F Configuration Pack
can be obtained on the Internet
(
http://support.automation.siemens.com/WW/view/en/15208817).
–
S7 F Systems
V5.2 SP3 or higher
You should also observe the readme file for the
F Configuration Pack
and the operating
instructions for your F system.
● To connect ET 200S fail-safe modules to PROFINET IO modules with Distributed Safety,
you need:
– ET 200S fail-safe modules
– F-CPU
–
STEP 7
V5.3 SP3 or higher
– IM 151-3 PN HIGH FEATURE interface module
–
S7 Distributed Safety
V5.4 or higher (for the order numbers specified in the "Preface":
F Configuration Pack
Version V5.5 SP5 or higher)
The current
F Configuration Pack
can be obtained on the Internet
(
http://support.automation.siemens.com/WW/view/en/15208817).
You should also observe the readme file for the
F Configuration Pack
and the operating
instructions for your F system.
