Siemens SIMATIC ET 200S Installation And Operating Manual

Fail-Safe Modules
7.4 PM-D F DC24V PROFIsafe Power Module
ET 200S Distributed I/O System - Fail-Safe Modules
Installation and Operating Manual, 08/2008, A5E00103686-07
99
Terminal assignment
On the PM-D F DC24V PROFIsafe, you connect only the 24 V DC load voltage power supply
and chassis. Wire the power module using the special terminal module.
The following table shows the terminal assignment of the PM-D F DC24V PROFIsafe for the
supported terminal module TM-PF30S47-F1 (order number 3RK1 903-3AA00).
Table 7- 12 Terminal Assignment of the TM-PF30S47-F1
Terminal Designation
20 24 VDC 24 VDC rated load voltage for:
• Inserted power module and
• Voltage buses SG 1 through SG 6 and U1
21 M Ground
27 24 VDC 24 VDC rated load voltage for:
• Inserted power module and
• Voltage buses SG 1 through SG 6 and U1
28 M Ground
