Siemens Simatic Field PG User Manual

Technical Specifications
B-4
SIMATIC Field PG Manual
A5E00075760-04
LC D display
Type TFT (Thin Film Transistor)
Size 246 mm x 185 mm, equivalent to 31 cm (14.1 in.)
Resolution 1024 x 768 (XGA)
Colors available max. 256 k
Horizontal frequency 37.8 kHz
Vertical frequency 60 Hz
Contrast 100 : 1
Brightness > 70 cd/m
2
Response time 50 / 50 ms (ton / toff)
Permissible defective areas bright pixel: max. 7
dark pixel: max. 9
Audio
Sound controller Intel 8201BA/BAM AC97
Compatibility Sound Blaster Pro and Microsoft Sound System, meets
PC98 / PC99 and WHQL specifications
Record and playback features Up to 16-bit stereo 48 kHz sampling rate, full duplex 3D
audio effects and ESFM(TM) music synthesizer
Internal speaker Max. power output 2 x 0.5 W
Keyboard
Type Standard notebook
Key spacing 19.05 mm
Key stroke 3 mm
Keytops international / German
Integrated pointing device Touchpad with 2 mouse buttons
Ports
COM1/TTY V.24 or TTY (20 mA) active or passive up to 100 m (25-pole
socket), no galvanic isolation
VGA Interface for external monitor (15-pole VGA socket)
Cardbus 2 interfaces for PC cards (type I, type II or type III);
Cardbus controller from TI: PCI 1420
Memory card Programming interface for SIMATIC memory cards
and S5 memory modules
Micro Memory Card Interface for Micro Memory Card
MPI/DP port
Transfer rate
Operating mode
Physical interface
Memory address area
IRQ
9–pole sub–D socket
9.6 Kbaud to 12 Mbaud, configurable per software
Galvanically isolated: data line A, B
control line RTS AS, RTS–PG
5V supl voltage (90mA max.)
Grounded: shielding of the DP12 patch cord
RS485, galvanically isolated
0CC00h...0CC7FFh or 0DC00h...0DC7FFh
5, 10, 11 or 15 configurable per software
USB 2 USB ports
1 x high-current max. (500mA), 1x low–current (100mA)
Ethernet RJ45, 10/100 Mbits,
Intel controller: Kinnereth DA82562ET
DC-In DC–voltage input, phono jack
