Getting Familiarized with the SIMATIC Field PG
2-8
SIMATIC Field PG Manual
A5E00075760-04
Bottom view
1
2
3
1 Rechargeable battery
The supplied rechargeable battery is installed behind a cover. The rechargeable
battery (Lithium-Ion) makes the device portable, independent of an external power
supply. The battery pack also prevents data loss in case of power failure. See also
section 3.3.
2 Memory expansion
You can install memory submodules in these slots to increase main memory.
Maximum memory expansion: 2 x 256 Mbytes. Remove the cover to access the
memory submodules. See also section 4.1.
3 Rating plate and Certificate of Authenticity
The rating plate and “Certificate of Authenticity” with the Microsoft Windows
“Product Key”. You need this to install new software.
