A-1
OP27, OP37 Equipment Manual
Release 05/99
Technical Data
Housing OP27 OP37
External dimensions Wx H 296 mm x 192 mm 482.6 mm x 310.3 mm
Mounting cutout W x H 282
+1
mm x 178
+1
mm 436
+1
mm x 295
+1
mm
Mounting depth without option
with direct key module and cable
with floppy disk drive
with AT expansion slot
59 mm
92 mm
–
–
85 mm
118 mm
118 mm
138 mm
Degree of protection
Front panel
Rear panel
IP65
IP20
Weight without option approx. 1.85 kg 8 kg
Processor OP27 OP37
Type 80486 Pentium
Clock frequency 33 MHz 100 MHz
Memory OP27M OP27C OP37
Flash 1 MB 2 MB
DRAM 2 MB 4 MB 8 MB
SRAM, battery-backed 128 kB
Floppy disk drive – 1.44 MB (optional)
Hard disk – 1.6 GB (optional)
Memory card
Slot A
Slot B
For flash/SRAM 1 MB
–
For hard disk 170 MB
For flash/SRAM 1 MB
A
