3-3
OP27,
OP37 Equipment Manual
Release 05/99
3.1 Changing
the Active W
indow
It
is possible to have several windows open at the same time on the OP
. It is
possible to switch between the following windows:
main screen
fixed window
message line/message window
Use the middle cursor key to switch between the various windows.
Key Description
A–Z
A–Z
A–Z
The cursor moves from one window to the next each time
the key is pressed.
The
window in which the cursor is located is the active window
, i.e. the one in
which entries and operator inputs can be performed. It is not possible to access
windows which do not have input fields.
The OP27 and OP37 react dif
ferently in respect of operation of an input field
when a window is open::
OP27:
The positions of windows displayed are static due to the small
size of the display; meaning that if an alarm message or pop-up
window is displayed, the input field beneath it cannot be oper
-
ated. Generally speaking, no input is possible until all windows
have been closed.
OP37:
When a dynamic window position is configured for the OP37,
any window being displayed automatically jumps to a position
in which the input field and the cursor are not concealed. In this
way
, input is always possible, regardless of display contents.
Overview
Window selection
Static and dynamic
windows
General Operation
