3-8
OP27,
OP37 Equipment Manual
Release 05/99
3.3 Enter
values
Use
the input fields on the OP to enter values which can then be downloaded to
the PLC. Carry out the following steps to do this:
Step Action
1
First, call the screen required, as described in Section 4.1.
2
Use the cursor keys to position the cursor on the necessary input field.
3
Enter the appropriate value. Depending on how the field is configured,
values can be entered as
Entering
Numeric V
alues (refer to Chapter 3.3.1),
Entering Alphanumeric Values (refer to Chapter 3.3.2),
Entering Symbolic V
alues (refer to Chapter 3.3.3).
4
Confirm the entry with the system key
ENTER
Cancel incorrect input by pressing the system key.
The original value is then entered automatically in the field.
Repeat input using the correct value.
ESC
Correct any incorrect input by inserting or deleting individual
characters at the cursor position by pressing
DEL
INS
Confirm the correction by pressing the system key
ENTER
Procedure
General
Operation
