Commissioning the device
4.3 Parameter assignment for Comfort Panel
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
105
4.3.6.10
Displaying information about the Comfort Panel
You can use this function to display device-specific information. You will need this
information if you contact Technical Support (https://support.industry.siemens.com
).
Requirement
The Control Panel is open.
Procedure
1. Open the "OP Properties" dialog using the "OP" icon.
2. Change to the "Device" tab.
①
HMI device name
②
Version of the HMI device image
③
Version of the bootloader
④
Bootloader release date
⑤
Size of the internal flash memory in which the HMI device image and project are stored
⑥
MAC address 1 of the HMI device
⑦
See "Restarting the HMI device (Page 89)."
Device-specific information is displayed.
Note
The size of the flash memory does not correspond to the available memory for a project.

Siemens SIMATIC HMI TP700 Comfort Specifications

General

Display Size	7 inches
Resolution	800 x 480 pixels
Power Supply	24 V DC
Number of Colors	16 million
Brightness	400 cd/m²
Touchscreen	Yes, analog resistive
Flash Memory	12 MB
Protection Rating	IP65 (front)
Display Type	TFT
Protection Class	Class III
Memory	1 GB Flash
Storage	12 MB Flash
Weight	1.2 kg
Power Consumption	12 W
Interfaces	1x Ethernet (RJ45), 2x USB, 1x RS422/RS485
