4.3.10.3
Entering the IP address and name server
You can change the network settings for the LAN connection under "Network&Dial-
Up Connections". You can also configure the properties of the Ethernet ports of the HMI
device.
Requirement
The Control Panel is open.
Procedure
Proceed as follows:
1. Open the network adapter display using the "Network&Dial-Up Connections" icon.
The image below shows the network adapter of a KP1500 Comfort.
The second network adapter "PN_X3" is present for the Comfort devices as of 15".
2. Open the "PN_X1" entry.
The 'PN_X1' Settings dialog opens.
3. Change to the "IP Address" tab.
4. Select the type of address assignment:
– To determine the address automatically, select "Obtain an IP address via DHCP".
– To determine the address manually, select "Specify an IP address".
