Commissioning the device
4.2 Operating the device
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
69
4.2
Operating the device
4.2.1
Reference for system keys
You operate key HMI devices using the system keys.
Alphanumeric assignment of system keys
The following table shows the alphanumeric assignment of the system keys from "0" to "9":
Key
Alphanumeric assignment
1
<space>\@#%?!"':;<>()[]{}€$&%^°~|_1
2
ABCÄÀ2
3
DEFÈÉ3
4 GHI4
5
JKL5
6 MNOÖ6
7
PRQRSß7
8
TUVÜ8
9
WXYZ9
0
+-*/=0
The characters available for input depend on the entry field involved, e.g. the entry of an
alphanumeric value using the system keys.
Key 1 <space> can be used instead of the <ENTER> key in the current project
General functions
You initiate functions on HMI devices with keys by using a key or keyboard shortcuts. With
keyboard shortcuts, hold the first key down. Then press the second button.

Siemens SIMATIC HMI TP700 Comfort Specifications

General

Display Size	7 inches
Resolution	800 x 480 pixels
Power Supply	24 V DC
Number of Colors	16 million
Brightness	400 cd/m²
Touchscreen	Yes, analog resistive
Flash Memory	12 MB
Protection Rating	IP65 (front)
Display Type	TFT
Protection Class	Class III
Memory	1 GB Flash
Storage	12 MB Flash
Weight	1.2 kg
Power Consumption	12 W
Interfaces	1x Ethernet (RJ45), 2x USB, 1x RS422/RS485
