Siemens SIMATIC HMI TP700 Comfort User Manual

Commissioning the device
4.3 Parameter assignment for Comfort Panel
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
143
Procedure
1. Press "Next". The "Load from external memory device" dialog is displayed.
2. Select the storage medium with the project data in the "Accessible devices" group.
3. Press "Next". The projects that are located on the external storage medium are displayed
in the following dialog. The following figure shows an example.
4. Select the project that you want to load into the HMI device. Use "Details" to receive
additional information about the selected project.
5. Press "Next". The HMI device checks whether the project data can be loaded. The result
of the check is displayed in the "Load Preview" dialog.

Siemens SIMATIC HMI TP700 Comfort Specifications

General

Display Size	7 inches
Resolution	800 x 480 pixels
Power Supply	24 V DC
Number of Colors	16 million
Brightness	400 cd/m²
Touchscreen	Yes, analog resistive
Flash Memory	12 MB
Protection Rating	IP65 (front)
Display Type	TFT
Protection Class	Class III
Memory	1 GB Flash
Storage	12 MB Flash
Weight	1.2 kg
Power Consumption	12 W
Interfaces	1x Ethernet (RJ45), 2x USB, 1x RS422/RS485
