Commissioning the device
4.3 Parameter assignment for Comfort Panel
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
81
Representation types for the screen keyboard
You can toggle the screen keyboard display as follows.
Alphanumerical screen keyboard
The alphanumerical screen keyboard has the following levels.
Normal level
HMI device with 4" display
HMI device with 7" display diagonal or larger
Note
The ' character on the keyboard is only displayed when followed by a space. If the '
character is followed by a letter, then the result will be an accent, such as "á".
Shift level
The shift level has uppercase letters and other special characters.
The alphanumeric keyboard is always displayed after a restart.
Numerical screen keyboard
By pressing the "Num" button, you can switch between the numerical and alphanumerical
screen keyboard.
