ET 200S Interface Module IM 151/CPU
A5E00058783-01
B.8 ORing of AND Operations
The ORing of AND functions is carried out according to the principle: AND before
OR.
In-
str c
Address
Description
Length
i
Typical Execution Time in
struc-
tion
Address
ID
Description
in
Words
Typical
Execution
Time
in
s
O The ORing of AND functions is carried out
according to the principle: AND before OR.
1 0.5
Status word for: O BR A1 A0 OV OS OR STA RLO /FC
Instruction depends on: – – – – – Yes – Yes Yes
Instruction controls: – – – – – Yes 1 – Yes
