ET 200S in the PROFIBUS Network
3-7
ET 200S Interface Module IM 151/CPU
A5E00058783-01
3.3 Network Components
To connect the ET 200S to the PROFIBUS-DP network, you need the following
network components:
Table 3-1 Network Components
Purpose
Network Components Order Numbers
To set up the network Cables (e.g. 2-core,
shielded or 5-core,
unprepared)
6XV1 830-0AH10
(2-core)
6XV1 830-0BH10
(2-core with PE sheath)
6XV1 830-3CH10
(2-core, for festoon
attachment)
6XV1 830-3BH10
(drum cable)
6XV1 830-3AH10
(direct-buried cable)
6ES7 194-1LY00-0AA0-Z
(5-core with PVC sheath)
6ES7 194-1LY10-0AA0-Z
(5-core; oil-resistant, can be
dragged, conditionally
resistant to welding; with PUR
sheath)
To connect the
programming device and
the ET 200S on the
PROFIBUS-DP network
Bus connector without a
programming device socket
(up to 12 Mbps)
6ES7 972-0BA10-0XA0
(with a straight outgoing cable
unit)
6ES7 972-0BA40-0XA0
(with a slanted outgoing cable
unit)
To make a dual connection
– for the programming
device and the DP master
on the PROFIBUS-DP
network, for example – via a
DP interface (see
Figure 3-5)
Bus connector with a
programming device socket
(up to 12 Mbps)
6ES7 972-0BB10-0XA0
(with a straight outgoing cable
unit)
6ES7 972-0BB40-0XA0
(with a slanted outgoing cable
unit)
To connect the programming
device to the bus connector
with the programming device
socket
Programming device
connecting cable (up to
1.5 Mbps)
6ES7 901-4BD00-0XA0
