Commissioning and Diagnostics
4-2
ET 200S Interface Module IM 151/CPU
A5E00058783-01
4.1 Configuring the IM 151/CPU
Configure the IM 151/CPU interface module as a DP slave or as a stand-alone
module.
The IM 151/CPU is presented to the user in
STEP7
as an S7-300 module that is
always created together with a rack in an S7-300 station. Similarly, the module can
only be deleted with the rack!
Expansion racks cannot be configured in an S7-300 station that contains an
IM151/CPU. The IM 151/CPU is positioned at slot 2 and receives a DP submodule.
This configuration applies both to the variant with RS 485 and the variant with a
fiber-optic cable connection. The first plug-in modules can be configured as of
slot 4.
The following configuration options are available:
Table 4-1 Configuration Options
Configuration
Environment
Configuration Tool Configurable Operating Mode
SIMATIC S7
STEP 7
(HWCONFIG)
as of V5.1
Stand-alone
IM 151/CPU as S7 slave
SIMATIC S5 COM PROFIBUS Fully configured and
programmed IM 151/CPU,
integrated as a standard
intelligent slave in COM
PROFIBUS
Non-Siemens
systems
Non-Siemens tool Fully configured and
programmed IM 151/CPU,
integrated as a standard
intelligent slave in a
non-Siemens tool
Prerequisite
You must have
STEP 7
(as of V 5.1) open and be working in
STEP 7
SIMATIC
Manager.
