Siemens SIMATIC IM 151/CPU User Manual

Product Overview
1-3
ET 200S Interface Module IM 151/CPU
A5E00058783-01
View
The figure below shows a sample configuration of an ET 200S with an
IM 151/CPU.
IM 151/CPU
Interface module
PM-E power mo-
dule for electronic
modules
Electronic modules
Power module for the
PM-D motor starter
Direct-on-line
starter
Reversing starter
TM-E terminal modules
for electronic modules
Power bus
Terminating module
TM-P terminal
modules for
power modules
Figure 1-1 View of the ET 200S Distributed I/O System with the IM 151/CPU
