Siemens SIMATIC IM 151/CPU User Manual

Commissioning and Diagnostics
4-25
ET 200S Interface Module IM 151/CPU
A5E00058783-01
Table 4-13 SSL Sublists of the IM 151/CPU
Sublist SSL ID
Extract
Sublist ExtractSSL ID
Sublist
Module status information W#16#xy91 Module status information of all
inserted modules
Module status information of a
module in a central configuration
or at a integrated DP interface
modules
Module status information of all
modules in the specified
mounting rack/DP station
W#16#0A91
W#16#0C91
W#16#0D91
Mounting rack/station status
information
W#16#xy92 Preset status in the central
configuration of the master
system
Actual status in the central
configuration of the master
system
OK status of the expansion units
of the master system
SSL sublist header information
only
W#16#0092
W#16#0292
W#16#0692
W#16#0F92
Diagnostic buffer W#16#xyA0 All the entries that can be
delivered in the operating mode
The most recent entries
W#16#00A0
W#16#01A0
Module diagnostic information
(DS 0)
W#16#00B1 – –
Module diagnostic information
(DS 1), physical address
W#16#00B2 – –
Module diagnostic information
(DS 1), logical address
W#16#00B3 – –
