Siemens SIMATIC IM 151/CPU User Manual

Technical Specifications
6-7
ET 200S Interface Module IM 151/CPU
A5E00058783-01
Programming
Programming language STEP 7
Stored instructions See Appendix B
Nesting levels 8
System functions
(SFCs)
See Appendix C
System function blocks
(SFBs)
See Appendix C
User program security Password protected
Dimensions and Weight
Installation dimensions
WHD (mm) 60 x 119.5 x 75
Weight Approx. 200 g
Voltages, Currents
Power supply Rated value 24 V DC
 Permissible range 20,4 to 28,8 V
 Polarity reversal
protection
Yes
 Voltage failure
buffering
20 ms
Insulation tested at 500 V DC
Current consumption
from supply voltage
(1L+)
Approx. 250 mA
 Power supply for the
ET 200S backplane
bus
Max. 700 mA
Power losses Typically 3.3 W
