Copper Ethernet Modules
3.7RUGGEDCOM RX1500PN M12 4TX03B
Pin Signal
1 Reserved (Do Not Connect)
a
2 Reserved (Do Not Connect)
a
3 Reserved (Do Not Connect)
a
4 TX-
5 RX+
6 TX+
7 Reserved (Do Not Connect)
a
8 RX-
a
Terminated at GND (Ground)
Technical Specifications
General Power Consumption 5 W
Connector M12 (8-Pin, A-Coded, Controlled
Bypass)
Speed 100 Mbps
Interface TX
Duplex FDX/HDX
Cable Type > CAT-5
Wiring Standard TIA/EIA T568A/B
Maximum Distance 100 m (328 ft)
Interface/Cable
Isolation 1.5 kV
Operating Temperature -40 to 85 °C (-40 to 185 °F)
Operating Relative Humidity 5 to 95% (non-condensing)
Environment
Storage Temperature -40 to 85 °C (-40 to 185 °F)
Certification
This module has been certified to comply with the requirements of the following
standards.
Certification Details
RoHS This module is declared by Siemens AG to meet the requirements of
the following RoHS (Restriction of Hazardous Substances) directives
for the restricted use of certain hazardous substances in electrical
and electronic equipment:
• China RoHS 2
Administrative Measure on the Control of Pollution Caused by
Electronic Information Products
A copy of the Material Declaration is available online at https://
support.industry.siemens.com/cs/ww/en/view/109738831.
Ordering Information
Description 4 x 10/100TX 8-pin M12 with Controlled Bypass
RUGGEDCOM Modules
Catalog, 07/2021, C79000-G8976-1320-16
59
