Siemens SIMATIC NET S7-300 User Manual

7 Programming FCs (Functions) and FBs for S7 Ethernet CPs
A-218
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
Paramete
r
Meaning / RemarkPossible
Values
TypeDeclarati
on
ERROR OUTPUT BOOL 0: No error
1: Error
Error code
For the meaning of this parameter in
conjunction with the DONE and STATUS
parameters, refer to the following table 7-6.
STATUS OUTPUT WORD See Table 7-6 Status code
For the meaning of this parameter in
conjunction with the DONE and ERROR
parameters, refer to the following table 7-6.
RESULT1 OUTPUT DWORD See Table 7-7 Information returned according to the
command sent to FC AG_CNTRL.
RESULT2 OUTPUT DWORD See Table 7-7 Only to be evaluated for S7-400:
Part 2 of information returned according to the
command sent to FC AG_CNTRL.
Condition Codes
The following table 7-6 shows the condition codes formed by the DONE, ERROR
and STATUS parameters that must be evaluated by the user program.
The command results must also be evaluated in the RESULT1/2 parameters
according to Table 7-7.
Table 7-6 AG_CNTRL Codes
DONE ERROR STATUS Meaning
1 0 0000H A job (CMD) was transferred successfully to the CP (for example
RESET) or a status was read successfully from the CP.
The RESULT1/2 parameters can be evaluated.
0 0 0000H There has been no block call yet or the block was called with
ACT=0.
0 0 8181H Job active
The block call must be repeated with the same parameters until
DONE or ERROR is signaled.
0 1
8183
H
No configuration or the service has not yet started on the Ethernet
CP.
0 1
8186
H
The ID parameter is invalid. The permitted ID depends on the
selected command; see CMD parameter in Table 7-7.
0 1
8187
H
The CMD parameter is invalid.
0 1
8188
H
Sequence error in the ACT control (Note: this code does not
occur in the product version of the CP / firmware).
FC10 AG_CNTRL - continued

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
