7 Programming FCs (Functions) and FBs for S7 Ethernet CPs
A-235
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
Table 7-10 Codes for PN_InOut (FB88) and PN_InOut_Fast (FB90), Fortsetzung
DONE MeaningSTATUSERROR
0 1 8090H (S7-400 only)
Parameter assignment error
An incorrect module address was specified; the address points to
an empty slot.
Note (only with FB90):
In the following cases, the value 8181
H
is shown in STATUS (job
active); In actual fact, there is no communication:
 The address points to a slot that contains a different module
type.
 The addressed module is configured for PROFINET CBA
operation.
0 1 80A1H (only with FB90)
Possible communications errors:
 Station-internal connection to addressed module being
terminated;
 The configuration limits for connections of the CPU has been
exceeded;
 The interface is being reinitialized.
0 1 80B0H (S7-300 only)
Block error: The data record number is wrong.
This status can also occur after the following actions:
 Cold or warm restart after power DOWN/UP
 Cold or warm restart on the CPU
0 1 80B1H (S7-300 only)
Block error: Data record length or offset wrong.
0 1 80B3H (S7-300 only)
Parameter error: Wrong CP address.
0 1 80C1H (S7-300 only)
Temporary error: The specified data record is currently being
processed.
0 1 80C2H (S7-300 only)
Temporary error: There is a job bottleneck; the data record cannot
be read yet.
0 1 80C3H (S7-300 only)
Temporary error: Resources (memory) in use.
0 1 80C4H (S7-300 only)
Communication error: occurs temporarily and a repetition in the
user program will often remedy the problem.
0 1 80D0H (S7-300 only)
Configuration error:
The maximum number of blocks of input and output data has
been exceeded; the interface DB is too large.
FB88 PN_InOut / FB90 PN_InOut_Fast - continued

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
