7.8.2 FC12 PNIO_RECV
The PNIO_RECV FC is used to accept data in the PROFINET IO controller or
PROFINET IO device CP modes.
 Operation as PROFINET IO controller
The block accepts the process data from PROFINET IO devices (inputs of the
controller) and transfers the IO provider status (IOPS) from the PROFINET IO
devices to the specified input areas.
 Operation as PROFINET IO device
The block receives the data transferred by the PROFINET IO controller
(configured O addresses) as well as the IO Provider Status (IOPS) of the
PROFINET IO controller and writes them to the data areas on the CPU of the
PROFINET IO device reserved for the process outputs.
Call Interface
Call interface in FBD representation
CPLADDR
NDR
PNIO_RECV
LEN
ERROR
STATUS
WORD
INT
WORD
BOOL
BOOL
IOPS ANY
RECV
ANY
CHECK_IOPS BOOL
ADD_INFO WORD
Example in STL representation
STL Explanation
call fc 12
CPLADDR :=W#16#0100
LEN :=7
IOPS :=P#DB11.DBX7.0 BYTE 1
NDR :=M 74.0
ERROR :=M 74.1
STATUS :=MW76
CHECK_IOPS :=M74.2
ADD_INFO :=MW 26
RECV :=P#DB11.DBX0.0 BYTE 7
//PNIO_RECV block call
//Module address from hardware configuration
//Length of the data area
//Per receive data byte one status bit in DB11
//Address for return parameter NDR
//Address for return parameter ERROR
//Address for return parameter STATUS
//Address for return parameter CHECK_IOPS
//Diagnostic information
//Received data in DB11 (7 bytes)
