1 Communication via Ethernet CPs in S7 Stations
A-26
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
1.3.2 OP Operation: Connecting Operator Interface Devices via
Industrial Ethernet
Requirements
Operation allowing operator interface functions is possible when the following
conditions are met:
 The following are installed in the operator control and monitoring device:
- an Ethernet CP
- SOFTNET S7 for Ind. Ethernet or software from the SIMATIC NET CD.
 The CPs in the S7 stations are supplied with a MAC/IP address (use the default
MAC address or set an IP address).
Procedure
To be able to use S7 communication, address the required module in the SIMATIC
S7 PLC on your operator interface system.
For more detailed information, please refer to the description of your operator
control and monitoring devices and in /4/.

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
