Characteristics and Technical Specifications of the SM 335
1-9
SM 335 – High-Speed Analog Input/Output Module for the SIMATIC S7-300
6ES7 335-7HG00-8BA1
Table 1-3 Technical specifications for the analog inputs
Analog value formation for the outputs
Measuring principle Successive approximation
Conversion time (per channel) in ms
• Basic conversion time for 4 channels in ms
Max. 200
Max. 1
Resolution
• Bipolar
• Unipolar
13 bits + sign
14 bits
Data of output to sensor supply
Rated voltage 10 V
Max. output current 25 mA
Short-circuit-proof Yes
Operational limit
(over entire temperature range)
0.2%
Temperature drift 0.002%/K
Basic error for rated voltage 0.1%
