P1427 / 593 Delay time Nsetpoint has elapsed
300W 075W
Min Standard Max Unit Data type Effective
0 0 15000 ms T2 immed.
This parameter defines the delay time following which the bit ”Ramp-up complete” (ZSW.10) is
output.
If the actual speed value for the specified time is within the tolerance band (P1426), ZSW.10 is
output.
Note:
This parameter is visible in SimoCom A only in operating mode ”Speed setpoint” (P930).
Available with software version 2.0 and higher.
5.6.3 Gearbox–dependent parameters, factory default settings
Depending on the gearbox used, the parameters listed in Table 5-10
are pre–set before the equipment is supplied:
Table 5-10 Gearbox–dependent parameters (factory presetting – default)
Gearboxes P964:7 P3 P10 P16 P22 P28
Type
Step-
down
ratio
i
Gearbox
Gear-
box
code
Gearbox
step-
down
ratio
Maximum
velocity
Maximum
overcur-
rent
Maximum
accel-
eration
Maximum
current
i
Gearbox
– [mm/min] [A] [mm/s
2
] [A]
75 W motor: Gearbox–dependent parameters (factory default setting)
without gearbox 2049 1 30000 18.0 1000 9.0
4.5 2050 4.5 6660 13.33 225 7.8
8 2058 8 3750 7.5 125 4.6
Planetary
20.25 2059 20.25 1480 18.0 50 9.0
Planetary
gearbox
36 2060 36 830 11.11 30 7.9
gearbox
50 2061 50 600 8.0 20 5.6
126.5625 2062 126.5625 237 9.48 8 7.8
162 2063 162 185 7.4 6 6.0
Worm
5 2064 5 6000 18.0 200 9.0
Worm
gearbox
24 2065 24 1250 7.3 40 7.3
gearbox
75 2066 75 400 2.7 13 5.3
Gearbox–
dependent
parameters
